Parts List
XPR300 Instruction Manual 809480 403
Recommended spare parts
Plasma power supply – recommended spare parts
* Voltage dependent - Select accordingly
Gas connect consoles – recommended spare parts
Part number Description Designator Quantity
428810 Shield-fluid treatment filter – 1
027005 Coolant filter (fine) – 1
006113 Coolant check valve – 1
229640 Power source: 88 VAC – 264 VAC to 24 VDC PS1 1
229671
Power source: 88 VAC – 264 VAC to 48 VDC,
600 W
PS2 1
229679 Chopper assembly Chopper 1 1
428750 Control PCB PCB1 1
141371 I/O PCB PCB5 1
141384 Fan power distribution PCB PCB6 1
141425 Power distribution PCB PCB7 1
108709 Fuse:10 A, 250 VAC, time delay (on PCB7) F3, F4, F5 2
208397*
Fuse: 15 A, 600 V, Class R (used in 200 V,
208 V, 220 V, 240 V)
F1, F2
2
208395*
Fuse: 8 A, 600 V, Class R (used in 380 V,
400 V, 415 V, 440 V, 480 V, 600 V)
2
003277 Pilot arc relay CR1 1
229697
Inrush contactor assembly: 80 A, IEC AC-3,
3-phase, 120 VAC
IR_CON 1
003276* Main contactor (200 V, 208 V, 220 V, 240 V)
M_CON
1
429060*
Main contactor assembly (380 V, 400 V, 415 V,
440 V, 480 V, 600 V)
1
Part number Description Designator Quantity
011110 Air filter element – 1
223398 Pressure transducer (VWI and OptiMix only) P6 – P9 1
006167 Solenoid valve (VWI and OptiMix only) B4 – B5 1
141354 High-frequency, high-voltage ignition PCB PCB2 1
