Parts List
9
404 809480 Instruction Manual XPR300
Torch connect console – recommended spare parts
Torch – recommended spare parts
Part number Description Designator Quantity
141368 Ohmic contact PCB PCB2 1
223477 Pressure transducer with wire and connector P1 – P5, P14 1
006167 Solenoid valve B1 – B3 1
229965 Solenoid valve V4 – V12 1
Part number Description Designator Quantity
420220 Quick-disconnect/torch receptacle – 1
420221 Quick-disconnect torch – 1
420368 Water tube – 1
006155 Torch solenoid valve – 1
