Hypertherm XPR170 - Page 405

Wiring Diagrams
10
XPR170 Instruction Manual 810060 405
Process IDs: 9002, 9003, 9009
Block type Gas V1V4V5V6V7V8V9V10V11V12
Preflow
Ar/N
2
Off Off On Off Off On Off Off On Off
Cutflow
Ar/N
2
Off Off On Off Off On Off Off On Off
Piercing
Ar/N
2
Off Off On Off Off On Off Off On Off
Process IDs: 2027, 2101
Block type Gas V1V4V5V6V7V8V9V10V11V12
Preflow
N
2
/Air
Off Off Off On OffOffOffOffOffOff
Cutflow Air/Air On Off Off On OffOffOffOffOn Off
Piercing Air/Air On Off Off On OffOffOffOffOffOff
Process ID: 8002
Block type Gas V1V4V5V6V7V8V9V10V11V12
Preflow
N
2
/N
2
Off Off On OffOffOffOffOffOn Off
Cutflow
N
2
/N
2
Off Off On OffOffOffOffOffOn Off
Piercing
N
2
/N
2
Off Off On OffOffOffOffOffOn Off
Process IDs: 9011, 9012, 9013
Block type Gas V1V4V5V6V7V8V9V10V11V12
Preflow
Ar/N
2
Off On On Off Off On Off Off On Off
Cutflow
Ar/N
2
Off On On Off Off On Off Off Off Off
Piercing
Ar/N
2
Off On On Off Off On Off Off Off Off
Process IDs: 1060, 1061, 7016, 7017
Block type Gas V1V4V5V6V7V8V9V10V11V12
Preflow
N
2
/Air
Off Off Off On Off Off On Off On Off
Cutflow
O
2
/Air
On Off Off On Off Off On Off On On
Piercing
O
2
/Air
On Off Off On Off Off On Off On On
