www.hysecurity.com Dual Gate Systems D0559 Rev. A 65
Dual Gate Systems
Conguring two or more operators to work together as an interlocked pair (Primary/Secondary or Sally Port) or
sequenced gate system is easy to do with the Smart Touch Controller. There is no need to order a special model
or any adapters. The area of the board marked Dual Gate employs a 3-wire RS-485 serial port for communication
between the operators.
ConneCtIng an InterloCKed paIr (dual gate)
The Smart Touch Controller (STC) provides dual gate connections and programming features to connect a pair
of gate operators in a Primary/Secondary or interlocked Sally Port conguration. The STC software establishes
the communication protocols when wiring the two gate operators. A Primary/Secondary pair of operators can be
set for different open/close timing sequences and Sally Port gates are often used at correctional facilities. In Sally
Port congurations, one operator cannot open unless the other is fully closed. To learn how to connect the wiring
between operators, review the wire diagram on the next page.
NOTE: The operators do not have to be of the same type, but both need to have the most current and up-to-
date software version installed on the Smart Touch Controller. A StrongArm M30/M50 can be interlocked with
a SlideDriver to provide both crash and personnel security. The STC software integrates seamlessly between
operators.
RS-485 communication is available for networked security systems. Refer to Integrating with Security Systems on
page 51 for additional information.
