2.5 Installation of rod type
2-25
2. Installation
[When using front brackets]
Either the enclosed fixing nuts or
the bracket screws can be used.
→
For precautions for mounting, refer to pages 2-27 to 28.
Ty
p
e
Mounting
screw
M
Spigot
diameter
N
Screw
effective
length
A
Boss
height
B
Fixing
nut
thickness
C
Tightening
torque
EC-R6
M42×1.5
φ
42
18mm
22mm
6mm
30.00N
･
m
EC-R7
M48×1.5
φ
48 23mm
27mm
9mm
35.00N
･
m
A
: Screw effective length
Front fixing nut
156
158
