2.7 Installation of high rigidity radial cylinder type
2-56
2. Installation
[When using the tapped mounting hole on the base bottom]
The unit has a tapped mounting hole at t
he bottom of the base for mounting.
→
For details regarding the position and di
mensions, refer to "Chapter 9 External
Dimensions".
T
apped mounting hole dimensions
Ty
p
e
Ta
p
diameter
A
Effective thread
depth
EC-RR6
□
AH
EC-RR6
□
H
M4
51mm
8mm
EC-RR7
□
AH
EC-RR7
□
H
M5 61mm
10mm
