IAI EC-S7 - Page 25

Part Names
Intro-16
High rigidity slider type (EC-S□□H)
Rod type
Sheet clamp
Opposite side
Stainless steel sheet
Slider cover
Slider
Front cover
Side cover
Track housing cover
Base
Motor cover
End cover
Power I/O connector
Status LED
Teaching port
Right side
Left side
Motor side
Motor cover base
Right side
Left side
Greasing port
(Rubber cap)
Front fixing nut
Opposite side
Motor side
Rod bearing
Front bracket
Frame
Bracket cover
Motor cover
Motor cover base
End cover
Teaching port
Status
indicator LED
Power I/O connector
Rod
Rod tip adaptor
