10. Appendix
10.2 How to use the home mark
As necessary, affix these marks to the product to mark the home position of the actuator.
Contents of sticker
Home mark sticker
× 1 sheet
Home mark scale × 4 Home mark × 4
(Scale: 1mm graduation mark, 10mm width)
䈄
Peel off the home marks and use as a base sheet.
Note 1. Every mark has an adhesive back.
2. Remove smears and stains from the surface before affixing the marks.
3. Avoid labels or nameplates as a marking location.
Example of Use
[1] Used as home position
On the slider
Motor
Motor
On the slider
On the base
䈄
Place the two marks when the actuator is stopped at the home position.
[2] Used as stop positions
At stop positions on the base
To Next Page
