4
CAUTION
BE SURE TO CHECK SCREW LENGTH.
DAMAGE CAN OCCUR IF TOO LONG OF SCREWS ARE USED!
Model Actuator Base Thread Depth
SA5 4 mm or more and 7 mm or less
SA6 5 mm or more and 9 mm or less
SA7 5 mm or more and 9 mm or less
SS7 5 mm or more and 8 mm or less
SS8 8 mm or more and 10 mm or less
HS8 8 mm or more and 10 mm or less
