IBM 7028 6C4 User Manual

Minimum Aisle Width > 838 mm (33 in.)
Minimum Aisle Width > 1193 mm (47 in.)
Half Aisle Width
Half Aisle Width
Hot Aisle
Cold Aisle
Hot Aisle
Wall
a
a
b
c
Load Shedding Area
(Weight Distribution)
e
Service Clearance Areas
d=front service clearance
e=rear service clearance
f=side service clearance
Proposed Floor Layout for Multiple Systems
f
f
d
Service Clearance Area
Weight Distribution Areas
a=side weight distribution difference
b=front weight distribution difference
c=rear weight distribution difference
g=side service clearance
(two frame configuration, not shown)
116 Site and Hardware Planning Information
