Chapter 9. Physical Characteristics of the 7300 Series
This chapter provides the physical characteristics for the 7300 series of external devices.The following
information can help you plan for your external devices. You need only do physical planning for the
devices you have ordered.
Note: Footprints are not drawn to scale.
7318 Serial Communications Network Server Models P10 and S20
Dimensions
Height 44 mm 1.73 in.
Width 381 mm 15.00 in.
Depth 229 mm 9.00 in.
Weight
Maximum 2.6 kg 5.7 lbs.
Electrical
Power source loading 0.085
(typical in kVA)
Voltage range (V ac) 100 to 125 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(typical)
170 Btu/hr
Power requirements
(max)
50 watts
Maximum altitude 2135 meters (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 50°C
(50 to 125°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions* Operating Idle
L
WAd
4.9 bels 4.9 bels
L
pAm
N/A N/A
<L
pA
>
m
54 dBA 54 dBA
Impulsive or
prominent discrete
tones
No No
* See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
315
