7317 Model D10
Dimensions
Height 464 mm 18.3 in.
Width 490 mm 19.3 in.
Depth with device
handles
289 mm 11.4 in.
Weight
Minimum 31.8 kg 70 lbs.
Maximum 45.4 kg 100 lbs.
Electrical
Power source loading
(typical in kVA)
N/A
Voltage range (V dc) -40 to -65
Thermal output
(typical)
360 Btu/hr
Thermal output
(maximum)
600 Btu/hr
Power requirements
(typical)
106 watts
Power requirements
(maximum)
176 watts
Maximum altitude
(operating) class c
0 to 2133 m (0 to 7000 ft.)
Temperature
Requirements
Class C
Operating
10 to 40°C
(50 to 104°F)
Non-Operating
10 to 52°C
(50 to 125°F)
Humidity
Requirements)
Operating
(Noncondensing) 8 to 80%
Wet Bulb
Requirements
27°C (80°F)
Noise Emissions¹ Operating Idle
L
WAd
6.0 bels 6.0 bels
L
pAm
N/A dBA N/A dBA
<L
pA
>
m
47 dBA 47 dBA
Impulsive or
prominent discrete
tones
None None
Clearances Front Back Left Right
Install/Air Flow² 150mm(6 in) 0 0 0
Service³ 500mm(20 in) 0 0 0
Footprint
2
Width
490mm(19.3 in)
Depth
440mm(17.3 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
3. All service is performed at the front of the machine.
Chapter 2. Physical Characteristics of Systems 211
