7250 POWER GXT1000 Graphics Accelerator
Dimensions Desktop Deskside
Height 160 mm 6.3 in. 466 mm 18.3 in.
Width 460 mm 18.0 in. 160 mm 6.3 in.
Width (at pedestal 241 mm 9.5 in.
for deskside)
Depth 525 mm 21.0 in. 525 mm 21.0 in.
Weight
Minimum 13.6 kg 30 lbs. 13.6 kg 30 lbs.
Maximum 13.6 kg 30 lbs. 13.6 kg 30 lbs.
Electrical
Power source loading 0.5
(typical in kVA)
Voltage range (Vac)² 100 to 125 or 200 to 240 (autoranging)
Frequency (Hertz) 50 or 60
Thermal output
(typical)
850 Btu/hr
Power requirements
(typical)
250 Watts
Power factor 0.5 to 0.7
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions¹ Operating Idle
L
WAd
5.2 bels 5.2 bels
L
pAm
N/A N/A
Impulsive or
prominent discrete
tones
No No
Noise Emissions¹
<L
pA
>
m
36.8 dBA
Clearances Front Back Left Right
Install/Air Flow³ 152 mm(6 in) 152 mm(6 in) N/A N/A
Service 152 mm(6 in) N/A N/A N/A
Footprint
3
Width Depth
Desktop 460mm(18 in) 830mm(33 in)
Deskside 241mm(9.5 in) 830mm(33 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The power supply may be autoranging or switchable. The switchable type has a red voltage selection switch near
the power cord connector.
3. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
Chapter 8. Physical Characteristics of the 7200 Series 313
