2105 Models E10, F10, E20, F20, and 800 Enterprise Storage Servers
For more information on the 2105 Models E10, F10, E20, F20, 800 and E20, F20, or 800 with the
expansion enclosure, see note 1 below.
Dimensions
Height 1915 mm (75.3 in.)
Width E10, F10, E20, F20, 800 1383 mm (54.4 in.)
Width E20, F20, 800 with Expansion Enclosure 2938 mm (115.7 in.)
Depth 909 mm (35.8 in.)
Weight
various configurations See 2105 Enterprise Storage Server Clearances and Floor Loading on page 240.
Electrical
Power source loading for Max. E10, F20 3.5 kVA
Power source loading for Max. E20, F20 5 kVA
Voltage low range (V ac) 200 to 240
high range (V ac) 380 to 480
Frequency (hertz) 50 or 60
Thermal output (Maximum) E10, F10 11000 Btu/hr
Thermal output (Maximum) E20, F20 16000 Btu/hr
Power factor 0.9
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements ²
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 20 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions³ Operating
L
WAd
All Models 7.5 to 7.75 bels
Service Clearances See “2105 Enterprise Storage Server Clearances and Floor Loading” on page 240.
Floor Loading See “2105 Enterprise Storage Server Clearances and Floor Loading” on page 240.
1. For more information see Enterprise Storage Server Introduction and Planning Guide, order number GC26-7294.
2. The recommended operating temperature is 22°C (72°F) or lower. At lower temperatures, the risk of failure in the
unit is reduced. If the operating temperature is above 22°C (72°F) for long periods of time, the unit will be
exposed to a greater risk of failure from external causes.
3. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
Chapter 5. Physical Characteristics of the 2100 Series 239
