7008 POWERstations M20 and M2A
Dimensions
Height 413 mm 16.1 in.
Width 410 mm 16.0 in.
Depth 459 mm 17.9 in.
Weight
Minimum 23.5 kg 52 lbs.
Maximum 23.5 kg 52 lbs.
Electrical
Power source loading 0.22
(typical in kVA)
Voltage range (V ac) 100 to 127 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(typical)
550 Btu/hr
Power requirements
(typical)
160 watts
Power factor 0.5 to 0.7
Inrush current 20 amps at 120 V ac, 40 amps at 240 V ac
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C (73.5F) 27°C (80.5F)
Noise Emissions¹ Operating Idle
L
WAd
5.0 bels 5.0 bels
L
pAm
38 dBA 38 dBA
<L
pA
>
m
38 dBA 38 dBA
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow² N/A 152 mm(6 in) 76 mm(3 in) 76 mm(3 in)
Service Install so that it can be moved to an area providing 760 mm (30 in) on each side.
Footprint² Width
562 mm(22 in)
Depth
611 mm(23.9 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
Chapter 2. Physical Characteristics of Systems 11
