3570 Models B00 and C00
Dimensions Horizontal Vertical
Height 112 mm 4.4 in. 320 mm 12.6 in.
Width 320 mm 12.6 in. 112 mm 4.4 in.
Depth 338 mm 13.3 in. 338 mm 13.3 in.
Weight
Minimum 8.4 kg 18.5 lbs. 8.4 kg 18.5 lbs.
Maximum (with stand) 8.5 kg 18.7 lbs. 8.5 kg 18.7 lbs.
Electrical
Power source loading 0.06
(typical in kVA)
Voltage range (V ac) 100 to 127 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output
(typical)
205 Btu/hr
Power requirements
(typical)
60 watts
Power factor 0.99 (100 V ac) or 0.95 (200 V ac)
Inrush current 30 amps at 100 V ac, 40 amps at 220 V ac
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(61 to 90°F)
Non-Operating
10 to 43°C
(50 to 109°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 26°C(79°F) 27°C(81°F)
Noise Emissions¹ Operating Idle
L
WAd
5.5 bels 5.5 bels
L
pAm
N/A N/A
<L
pA
>
m
37dBA 37dBA
Impulsive noise None None
Prominent discrete
tones
None None
Clearances Front Back Left Right
Install Air Flow² 76 mm (3 in) 76 mm (3 in) None None
Service No additional clearance is needed for service.
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. Air flow is 25 CFM
246 Site and Hardware Planning Information
