IBM 7028 6C4 User Manual

S85 Rack Caster Location
The following figure shows the caster locations for the S85 rack. For complete specifications on the S85
system rack, see “7017 Model S85” on page 49.
567 mm (22.3 in.)
1041 mm
(40.9 in.)
Front
Front Caster Location
Note: Rear
Swivel Caster
Contacts Floor
21 mm (0.8 in.)
Radius From
Center Point
2X
(4.2)106
(2.5)
64
See
Note
2X
(4.4)112
(2.5)
64
Chapter 2. Physical Characteristics of Systems 51
