Chapter 7. Physical Characteristics of the 7100 Series
This chapter provides the physical characteristics for the 7100 series of external devices. The following
information can help you plan for your external devices. You need only do physical planning for the
devices you have ordered.
Note: Footprints are not drawn to scale. Where a footprint is shown, the figure represents a top view of
the device.
7131 Model 105 SCSI Multi-Storage Tower
Dimensions
Height 407 mm 16.0 in.
Width (at pedestal) 197 mm 7.8 in.
Depth 483 mm 19.0 in.
Weight
Minimum 15.4 kg 34 lbs.
Maximum 20.0 kg 44 lbs.
Electrical
Power source loading 0.76 to 0.96
(typical in kVA)
Voltage range (V ac) 100 to 125 or 200 to 240 (selectable)
Frequency (hertz) 50 or 60
Thermal output (max) 1638 Btu/hr
Power requirements (max) 480 watts
Power factor 0.5
Maximum altitude 2135 m (7000 ft.)
Temperature Requirements Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity Requirements Operating Non-Operating
(Noncondensing) 20 to 80% 20 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions¹ Operating Idle
L
WAd
(5 devices) 6.0 bels 5.6 bels
L
pAm
N/A N/A
<L
pA
>
m
50 dBA 46 dBA
Impulsive or prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow² 152 mm(6 in) 152 mm(6 in) 25 mm(1 in) 25 mm(1 in)
Service 152 mm(6 in) N/A N/A 25 mm(1 in)
Footprint
2
Width
250mm(9.8 in)
Depth
790mm(31 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
267
