7015 Models R10, R20, and R21 CPU Drawers
Dimensions
Height 266.7 mm 10.5 in.
Width 445.5 mm 17.5 in.
Depth 610.0 mm 24.0 in.
Weight
Minimum 30.3 kg 65 lbs.
(Configuration
dependant)
Electrical
Power source loading 0.29KVA
(typical in kVA)
Voltage range (V ac) 200 to 240
Frequency (hertz) 50 or 60
Thermal output
(typical)
850 Btu/hr
Power requirements
(typical)
250 watts ( Model R10)
280 watts (Model R20)
Power factor 0.85 min
Inrush current³ 20 amps
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
10 to 40°C
(50 to 104°F)
Non-Operating
10 to 40°C
(50 to 104°F)
Humidity
(Noncondensing)
Operating Non-Operating
Without tape drive 8 to 80% 8 to 80%
With tape drive 20 to 80% 20 to 80%
Wet Bulb
Requirements
Without tape drive 27°C (80°F) 27°C (80°F)
With tape drive 23°C (73°F) 27°C (80°F)
Noise Emissions
1,2
Operating Idle
L
WAd
6.4 bels 6.2 bels
L
pAm
N/A N/A
<L
pA
>
m
49 dBA 47 dBA
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air flow.
Service (See service clearances for the R00 System Rack)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. Noise emissions data for Models R10 and R20 CPU Drawers are based on a processor drawer mounted in a
R00 System Rack.
3. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
Chapter 2. Physical Characteristics of Systems 43
