3590 Magstar Tape System
3590 Magstar Tape System Models B11 and B1A
Dimensions B11 Rack B1A Library
Height 522 mm 20.6 in. 262 mm 10.5 in.
Width 230 mm 9.1 in. 221 mm 8.8 in.
Depth 988 mm 39.0 in. 750 mm 29.8 in.
Weight
49.5 kg 109 lbs. 28.6 kg 63 lbs.
Electrical
Power source loading 0.3
(typical in kVA)
Thermal output
(typical)
1024 Btu/hr
Temperature Requirements
(media in use) 16 to 32°C
(60 to 90°F)
Humidity Requirements
(Noncondensing) 20 to 80%
Wet Bulb 23°C (73°F)
3590 Magstar Tape System Model C12 Frame
Dimensions
Height 1803 mm 71.0 in.
Width 724 mm 28.5 in.
Depth 775 mm 30.5 in.
Weight
400 kg 880 lbs.
Electrical
Power source loading 1.2
(typical in kVA)
Thermal output
(typical)
7830 Btu/hr *
Temperature Requirements
(media in use) 16 to 32°C
(60 to 90°F)
Humidity Requirements
(Noncondensing) 20 to 80%
Wet Bulb 26°C (79°F)
Note: * Includes four B1A or E1A drives and associated cables
256 Site and Hardware Planning Information
