Chapter 5. Physical Characteristics of the 2100 Series
This chapter provides the physical characteristics for the 2100 series of external devices. The following
information can help you plan for your external devices. You need only do physical planning for the
devices you have ordered.
Note: Footprints are not drawn to scale. Where a footprint is shown, the figure represents a top view of
the device.
2101, 2102, and 2103 Fibre Channel RAID Storage Subsystem
2101 Model 100 Seascape Solution Rack
Dimensions
Height 1580 mm 62.0 in.
Width 650 mm 25.5 in.
Depth 1030 mm 36.0 in.
40.5 in.
Weight (empty) 160 kg 352 lbs.
Electrical
Power source loading:
Maximum operating 2.7 kVA
Voltage range (V ac) 200 to 240
Frequency (hertz) 50 or 60
Thermal output
(Maximum)
9250 Btu/hr
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
10 to 40°C
(50 to 104°F)
Non-Operating
10 to 52°C
(50 to 125°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8% to 80% 8% to 80%
Wet Bulb 27°C (80°F) 27°C (80°F)
Noise Emissions* Operating Idle
L
WAd
6.6 bels NA bels
L
pAm
N/A N/A
<L
pA
>
m
NA dBA NA dBA
Impulsive or
prominent discrete
tones
N/A N/A
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air flow.
Service 915mm(36 in) 915mm(36 in) 915mm(36 in) 915mm(36 in)
* See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
229
