7133 Model T40 Deskside SSA Subsystem
Dimensions
Height 610 mm 24.0 in.
Width (at pedestal) 210 mm 8.3 in.
Depth 820 mm 32.3 in.
Weight
Minimum 58.5 kg 129 lbs.
Maximum 72.5 kg 160 lbs.
Electrical
Power source loading:
Maximum start-up 0.756 kVA
Maximum operating 0.636 kVA
Maximum idling 0.532 kVA
Power factor greater than 0.95
Voltage range (V ac) 88 to 264
Frequency (hertz) 50 or 60
Thermal output
(Maximum)
1880 Btu/hr
Maximum altitude 2133 m (7000 ft.)
Temperature
Requirements
(See note)
Operating
10 to 40°C
(50 to 104°F)
Non-Operating
10 to 40°C
(50 to 104°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 27°C (80°F) 27°C (80°F)
Noise Emissions¹ Operating Idle
L
WAd
6.6 bels 6.5 bels
L
pAm
N/A N/A
<L
pA
>
m
N/A N/A
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow * 152 mm(6 in) 152 mm(6 in) N/A N/A
Service 152 mm(6 in) N/A N/A N/A
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
Note: * The recommended operating temperature is 22°C (72°F) or lower. At lower temperatures, the risk of failure in
the unit is reduced. If the operating temperature is above 22°C (72°F) for long periods of time, the unit will be
exposed to a greater risk of failure from external causes.
Chapter 7. Physical Characteristics of the 7100 Series 271
