3590 Magstar Tape System Models E11 and E1A
Dimensions E11 Rack E1A Library
Height 522 mm 20.6 in. 262 mm 10.5 in.
Width 230 mm 9.1 in. 221 mm 8.8 in.
Depth 988 mm 39.0 in. 750 mm 29.8 in.
Weight
46.7 kg 103.0 lbs. 30.0 kg 66.0 lbs.
Electrical
Power source loading 0.225
(typical in kVA)
Thermal output
(typical)
770 Btu/hr
Temperature Requirements
(media in use) 16 to 32°C
(60 to 90°F)
Humidity Requirements
(Noncondensing) 20 to 80%
Wet Bulb 25°C (78°F)
Chapter 6. Physical Characteristics of the 3000 Series 257
