9348 Model 012 Magnetic Tape Unit
Dimensions
Height 222 mm 8.75 in.
Width 483 mm 19.0 in.
Depth 673 mm 26.5 in.
Weight
Minimum 48.2 kg 105 lbs.
Maximum 48.2 kg 105 lbs.
Electrical
Power source loading 0.27
(typical in kVA)
Voltage range (V ac) 100 to 125 or 200 to 240 (selectable)
Frequency (hertz) 50 or 60
Thermal output
(typical)
410 Btu/hr
Power requirements
(typical)
120 watts
Power factor 0.5 to 0.7
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 20 to 80% 20 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions¹ Operating Idle
L
WAd
7.0 bels² 6.8 bels
L
pAm
N/A N/A
<L
pA
>
m
51 dBA² 50 dBA
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow³ 152mm(6 in) 152mm(6 in) N/A N/A
Service 152mm(6 in) N/A 305mm(12 in) 305mm(12 in)
Footprint
3
Width
483mm(19 in)
Depth
977mm(38.5 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. Data applies when the tape unit is in streaming operating mode.
3. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
Chapter 10. Physical Characteristics of the 9000 Series 335
