PDU Location and Configuration Information
The following figure shows the four vertical PDU locations in a rack.
Power Distribution Unit Vertical Locations
L1
L1
L1
L1
1
2
3
4
Rack Rear View
Chapter 11. Power Cords and Electrical Needs 341
