T00 and T42 Service Clearances and Caster Location
The service clearances and caster locations are shown in the following illustration:
2474 mm (97.4 in.)
2921 mm
(115 in.)
915 mm
(36 in.)
915 mm
(36 in.)
915 mm (36 in.)
915 mm (36 in.)
Front
Caster
Location
Front cover
thickness
58 mm (2.4 in.)
Rear cover
thickness
20 mm (0.8 in.)
Side cover
thickness 2x
10 mm (0.4 in.)
(4.8)121
(3.1)
80
Cable opening
310 mm (12.2 in.)
x 50mm(2in.)
Chapter 2. Physical Characteristics of Systems 33
