IBM Aptiva Hardware Maintenance Guide

5-4
Table 5- 1 Machine Type 2137 System Board Family
FRU
Number
Description Refer to…
10L6595 Supports
Pentium P-166, -200 processor
Pentium MMX P-166, -200 -233 processor
Cyrix/IBM 6x86L PR166+, 200+ processor
Cyrix/IBM 6x86MX PR166+ processor
AMD K6-166, -200, -233 processor
AMD K6-266 (A9 stepping, core voltage 2.2V)
NOTE: 10L6595 may come with or without a port
bracket secured at rear side. If you have a board
without the port bracket, you can disassemble
from a defective board to replace it.
Figure 5-2
10L6653 Supports
Pentium P-166, -200 processor
Pentium MMX P-166, -200 -233 processor
Cyrix/IBM 6x86L PR166+, 200+ processor
Cyrix/IBM 6x86MX PR166+ processor
AMD K6-166, -200, -233 processor
AMD K6-266 (A9 stepping, core voltage 2.2V)
AMD K6-300 processor
NOTE: 10L6653 may come with or without a port
bracket secured at rear side. If you have a board
without the port bracket, you can disassemble
from a defective board to replace it.
Figure 5-2

IBM Aptiva Specifications

General

CPU	Intel Pentium
RAM	8 MB to 64 MB
Operating System	Windows 95
Graphics	S3, ATI
Optical Drive	CD-ROM
Ports	Serial, Parallel, PS/2
Expansion Slots	ISA, PCI
