IBM Aptiva Hardware Maintenance Guide

Parts/Test Point Locations 5-23
3.5-In. Hard Disk Drive Jumper Settings
The configuration of the following jumpers controls the drive’s mode of
operation:
•
SP – Slave Present
•
DS – Drive Select
•
CS – Cable Select
•
PK – Park, used as a place to store a jumper
Quantum Fireball TM and ST Series Hard Disk Drives
Table 5-12 Quantum Fireball TM and ST Series Hard Disk Drives Jumper
Settings
DS CS SP DESCRIPTION
On Off -- Drive configured as a Master, or
Drive configured as a Master, with an attached Slave
Off Off -- Drive configured as a Slave.
Seagate Hard Disk Drive
Table 5-13 Seagate Hard Disk Drive Jumper Settings
DS CS/SP DESCRIPTION
On Off Drive configured as a Master.
Off Off Drive configured as a Slave.
On On Drive configured as a Master, with an attached Slave
Maxtor Hard Disk Drive
Table 5-14 Maxtor Hard Disk Drive Jumper Settings
J50:Master/Slave DESCRIPTION
On Drive configured as a Master, or
Drive configured as a Master, with an attached Slave
Off Drive configured as a Slave.
