7-4
Assembly 2: Machine Type 2137 System Unit -
Interior
Asm-Index FRU Number Description
2-1 02K2332 Assembly Lower Case (with Power Supply
Frame, Driver Frame, Bracket Port, w/o
Housing Stands)
2-2 02K2333 Power Supply Frame
2-NS 02K2334 Screw for Power Supply Frame
2-3 01K4200 Bracket Port
2-4 02K2334 Screw for Bracket Port
2-5 02K2335 Assembly Wire LED
2-6 01K4213 Mounting Purse Lock
2-7 01K4192 EMI Core
2-8 02K2337 Housing Stand
