IBM Aptiva Hardware Maintenance Guide

Parts Catalog 7-5
Asm-Index FRU Number Description
2-9 12J6890 System Board V58XA-1,1N-600
2-9 02K2551 System Board V58XA-2CR, 220
2-9 10L6595 System Board V58XA-2, 220
2-9 10L6653 System Board V58XA-2, 220 (support K6-
300,Vpll 3.3V processor)
2-9 10L6659 System Board V58XA-2, 220 (support K6-
300,Vpll 3.3V processor, w/o ROC mark)
2-NS 02K2334 Screw for System Board
2-10 03K0345 Intel Pentium 200 MHz Processor
2-10 03K0346 Intel Pentium 166 MHz MMX Processor
2-10 03K0347 Intel Pentium 200 MHz MMX Processor
2-10 02K2271 Intel Pentium 233 MHz MMX Processor
2-10 02K2273 IBM 6x86MX-PR166 Processor
2-10 02K2275 AMD K6 166MHz Processor
2-10 02K2276 AMD K6 200MHz Processor
2-10 02K2277 AMD K6 233MHz Processor
2-10 12J6886 AMD K6 266MHz Processor
2-10 10L6632 AMD K6 300MHz Processor (Vpll 3.3V)
2-NS 02K2345 Flash ROM
2-11 02K2323 Processor Fan Sink
2-11 02K2269 Processor Fan Sink (for K6-233/266)
2-12 01K4278 Backup Battery (CR2032)
2-13 02K2287 DIMM 8MB
2-13 02K2288 DIMM 16MB
2-13 02K2289 DIMM 32MB
2-14 Modem Card, see page 7-9 to 7-11
2-15 02K2297 Power Supply 200W (API)
2-15 02K2562 Power Supply 200W for IDATX-2 Housing
2-15 02K2298 Power Supply 200W, (for JP)

IBM Aptiva Specifications

General

CPU	Intel Pentium
RAM	8 MB to 64 MB
Operating System	Windows 95
Graphics	S3, ATI
Optical Drive	CD-ROM
Ports	Serial, Parallel, PS/2
Expansion Slots	ISA, PCI
