7-20
Asm-Index FRU Number Description
3-1 02K2299 Assembly 1.44MB Diskette Drive
3-2 01K4259 Screw for Diskette Drive
3-3 02K2603 Diskette Drive Cable
3-4 10L6630 4.0GB Hard Disk Drive, 3/5-in.
3-4 02K2561 8.0GB Hard Disk Drive, 3.5-in.
3-4 10L6649 6.0GB Hard Disk Drive, 5.25-in.
3-4 10L6645 8.0GB Hard Disk Drive, 5.25-in.
3-5 01K4224 Hard Disk Drive Cable
3-NS 01K4260 Mounting Screw for 3.5-in. Hard Disk Drive
3-6 02K2607 3.5-in. Drive Frame
6
