Chapter 3 QUICK SETUP
QUICK SETUP Submenus
Print Intensity
This option specifies the level of thermal energy from the printhead to be used
for the type of media and ribbon installed.
Large numbers imply more heat (thermal energy) to be applied for each dot.
This has a significant effect on print quality. The print intensity and speed
must match the media and ribbon type to obtain the best possible print quality
and barcode grades.
The range is -15 through +15.
The factory default is -3.
Print Speed
This option specifies the speed in inches per second (ips) at which the media
passes through the printer while printing.
The range is 1 through 10 ips (in increments of 1 ips).
The factory default is 6 ips.
NOTE: The maximum print speed varies based on maximum printer width
and dot per inch (dpi) resolution of the printhead installed (203 or
300 dpi). See Table 18 on page 337.
Print Mode
This option specifies the type of printing to be done.
• Transfer. Indicates Thermal Transfer printing (ribbon installed).
• Direct. Indicates Direct Thermal printing (no ribbon) and requires special
heat sensitive media.
The factory default is Transfer.
1* 1-8
Factory* 1-8
Save Config.
Power-Up Config.
Disable* Enable
SMT
QUICK SETUP
(cont. from previous page)
To Next Page
