IBM InfoPrint 6700 Series User Manual

256
Chapter 3 SERIAL PORT
SERIAL PORT
Notes:
* = Factory Default
Italicized items are available only
when you enable Admin User (in the
PRINTER CONTROL menu).
SERIAL PORT
Baud Rate
Port Type
Word Length
57600 BAUD38400 BAUD19200 BAUD9600 BAUD*
600 BAUD 1200 BAUD 2400 BAUD 4800 BAUD
RS 232* RS 422 Disable
Trickle Time
2 sec1 sec1/2 sec1/4 sec* 4 sec
8 sec 16 sec Off
115200 BAUD
Stop Bits
Parity
MarkEvenOddNone* Sense
Buffer Size in K
16* 1-16
Timeout
10 sec.* 1-60 sec.
Report Status
Disable* Enable
Data Term Ready
On-Line and BNFTrue*
Off-Line or BF
On-Line False
Request to Send
On-Line and BNF*
Off-Line or BF
On-Line False True
Poll Character
00 Hex* 00-FF Hex
Poll Response
0 ms* 0-30 ms
Idle Response
Disable* Enable
One Char Enquiry
Disable* Enable
Printer Status
Disable* ENQ/STX ENQ
1* 2
8* 7
DTR
Data Protocol
Series1 1 CharACK / NAK ETX / ACKXON / XOFF* Series1 2 Char
Framing Errors
Enable* Disable
