138
Chapter 3 MEDIA CONTROL
The factory default is Head First when IGP/PGL or IGP/VGL is enabled.
The factory default is Foot First when PPI/ZGL is enabled.
Tear-Strip Time
When Media Handling is set to Tear-Off Strip or when Media Handling is set
to Continuous and Continuous Mode is set to Tear Strip Full, Tear-Strip Time
specifies the number of seconds after the buffer is empty that the printer will
wait before it advances media to the tear bar position.
The range is .1-60.0 seconds, and the factory default is 1.0 second.
Pre-Peel Mode
• Disable.
• Enable. When Media Handling = Peel-Off and Peel-Off Mode = Standard,
enabling Pre-Peel Mode adds a forward and reverse motion to each label
prior to printing. The added forward pre-peel motion temporarily breaks
the die cut label from the liner, and the reverse motion places the label
back on the liner prior to printing, peeling, or dispensing the label. Pre-
Peel Mode is usually enabled only when using die cut labels with an
aggressive adhesive that makes automatic label removal from the liner
difficult.
The factory default is Disable.
Pre-Peel Adjust
When Pre-Peel Mode = Enable, Pre-Peel Adjust represents the selectable
distance that the label advances during Pre-Peel Mode. The Pre-Peel Adjust
distance selected is automatically used when Pre-Peel Mode is enabled.
The range is 0.00 to 2.00 inches in .01 inch increments.
The factory default is 1.00 inch.
Table 5. Foot First
Print Direction
Option
Orientation Option
Result in Active IGP/ZGL
Emulation
Foot First Portrait Portrait
Foot First Landscape Inv. Landscape
Foot First Inv. Portrait Inv. Portrait
Foot First Inv. Landscape Landscape
