Drive Location SCSI ID Drive Description
CD-ROM Drive Bay D01 IDE (Non-SCSI) __________________
Media Device Bay D02 The SCSI ID can be
any number 0 through
15 with the exception
of 7 which is reserved
for the adapter.
__________________
Diskette Drive
(Optional)
Bay D02 ______
Hot-Plug Disk Bay 10 8 __________________
Hot-Plug Disk Bay 11 9 __________________
Hot-Plug Disk Bay 12 10 __________________
Hot-Plug Disk Bay 13 11 __________________
Appendix E. System Records
149
