M.
lever
Stop
.-
•
360"to
.375"
FIGURE
151.
Multiplying
Lever Stop
(New
Style)
Figure 152
illustrates
the
first level multiplying
lever
stop· used on
the
new
style
index
mechanism. This
stop
should
be
adjusted
both
horizontally
and
vertically.
The stop
is
adjusted
vertically
so
that
the
multiplying
lever
will
operate
above
and
below a horizontal position
by
an
equal
amount.
The horizontal
and
vertical
adjust-
ments
of
the
stop must be made
alternate
Iy
unti I both
are
correct.
.360"
to
.375"
FIGURE
152.
Multiplying
lever
Stop
(Early
level)
3.
Index Link - Use
the
following procedure
to
adjust
the
index link:
a.
As
a
preliminary
step,
loosen
the
platen
overthrow
stop
and
move
it
to
the
rear
(Fig.
153).
Platen
Overthrow
Stop
Moved
To
The
(Index
Operation
Manually
Ol'l
..
rat
.. d Through)
Rear
Index Link
FIGURE
153.
Index Link Adjustment
b.
With
the
platen
inst911ed, hold
the
detent
roller
dis-
engaged
from
the
platen
ratchet
with a spring hook
while
an
index
operation
is manually
cycled.
At
the
completion
of
the
operation
allow
the
detent
roller
to
re-enter
the
platen
ratchet.
If
the
index
link is
properly
adjusted
the
detent
roller
will
seat
between
two
ratchet
teeth
without
causing
any
ro-
tational
motion
to
the
platen.
Adjust
the
link
to
ob-
tain
this
condition.
4.
Platen
Overthrow
Stop
- With
the
index
cam
rotated
to
its high
point,
adjust
the
platen
overthrow stop
to
clear
the
index pawl
by
.005"
(Fig.
154) .
..l.o...-
__
Index Link
FIGURE
154.
Platen
Overthrow
Stop
5.
Index
Selection
Cam
2-46
a.
With
the
index
cam
latched
at
rest
and
tbe
selection
lever
in
the
double
line
space
position,
adjust
the
selection
cam front
to
rear
so
that
the
index
pawl
clears
the
platen
ratchet
by
.015"
to
.050"
(Fig.
155).
Index
Selector
Cam
FIGURE
155.
Index
Selection
Cam Adjustment
b.
Adjust
the
selection
cam up
or
down so
that
the
in-
dex
pawl
is
centered
on
the
cam
surface
with
the
selection
lever
in
the
single
line
space
position
(Fig.
156).
Pawl
Centered
FIGURE
156.
Vertical
Adjustment
Of
Index
Selection
Cam
