IBM StorVize V7000 Gen2+ - Insert the New FIB in the Chassis; Secure the FIB to the Drive Board

3. Use a cross head screwdriver to tighten the retaining screws that secure the
FIB to the drive board, as shown in Figure 85.
svc01031
Figure 84. Insert the new FIB in the chassis
svc01029
Figure 85. Secure the FIB to the drive board
Chapter 2. Installing the Storwize V7000 Gen2 and Storwize V7000 Gen2+ hardware 91
