IBM StorVize V7000 Gen2+ User Manual

Components on the rear of the enclosure
Figure 26 shows the components on the rear of the 2076-92F expansion enclosure.
Four fan modules and two expansion enclosures are accessible from the back of the
enclosure.
▌1▐ Power cable connector for PSU 2
▌2▐ Power cable retention clamps
x4
svc01042
Figure 25. Front fascia of the 2076-92F expansion enclosure
svc01010
8
77
8
1
2
4
5
3
6
9
Figure 26. Features on the rear of the 2076-92F expansion enclosure
Chapter 2. Installing the Storwize V7000 Gen2 and Storwize V7000 Gen2+ hardware 39

IBM StorVize V7000 Gen2+ Specifications

General

Model	Storwize V7000 Gen2+
Storage Type	Hybrid Flash Array
RAID Levels	RAID 0, 1, 5, 6, 10
Form Factor	2U
Operating System	IBM Spectrum Virtualize
Drive Types Supported	SSD
Host Interface	8/16 Gbps Fibre Channel, 1/10 Gbps iSCSI
Cache Memory	64 GB per control enclosure
Nodes	2 nodes per control enclosure
Processor Cores	8-core processor per node
Connectivity	Fibre Channel, iSCSI
