▌1▐ 4U fascia (front)
▌2▐ 1U fascia (power supply units)
12. Attach the 4U and 1U fascia to the front of the enclosure, as described in
“Installing or replacing the fascia: 2076-92F” on page 77.
13. Install the drives, as described in “Installing or replacing a drive: 2076-92F” on
page 69.
14. Replace the top cover, as described in “Installing or replacing the top cover:
2076-92F” on page 68.
15. Lower the mechanical lift so that you can remove the remaining foam blocks
away from the expansion enclosure.
16. Slide the latch on the side of each rail and push the expansion enclosure
securely into the rack, as described in steps 6 on page 56 through 8 on page
56 in “Installing or replacing an expansion enclosure in a rack: 2076-92F” on
page 49.
17. Remove the cable management arm assembly from its packaging (▌2▐ in
Figure 29 on page 42).
18. Attach the cable management arm, as described in “Installing or replacing the
cable-management arm: 2076-92F” on page 63.
19. Connect the SAS cables, as described in “Removing and installing a SAS cable:
2076-92F” on page 85.
20. Connect the power cables.
Removing the top cover: 2076-92F
To perform service tasks, you might need to remove the top cover from a 2076-92F
expansion enclosure.
Before you begin
Important: You can remove the cover without powering off the expansion
enclosure. However, to maintain operating temperature, replace the cover within 15
Figure 31. Packaging for fascia
44 Storwize V7000 Gen2 and Gen2+: Quick Installation Guide
