29
9
OTHER FUNCTIONS
9
RX Frequency D
The frequency of the RX channels can be re-programmed
within the 450–520 MHz frequency range, to allow the trans-
ceiver to listen to communications outside the standard CB
range. Please note that it is not possible to transmit on these
channels.
As standard, the RX channels will not appear when scrolling
through the list with [CH Up] and [CH Down]. In order to do
so, the RX channels will need to be enabled.
To enable individual receive channels:
While pushing and holding q
and , turn the trans-
ceiver ON to enter the receive channel enable mode.
Select the desired channel with [CH Up] and [CH Down], w
then push
to either set the channel as enabled or in-
hibited.
“Enable” setting“Inhibit” setting
e Turn the power OFF, then ON. (The enabled receive chan-
nels will now appear when scrolling through the chan-
nels)
To program the RX frequencies:
Select the desired RX channel (RX-XX), once enabled. q
Push [Top] to enter function mode, then push and hold w
[Top] for 2 seconds to enter the RX VFO mode.
Push e
to toggle between wide and narrow bandwidth.
RX VFO modeRX channel
(in function mode)
Appears when Narrow
channel spacing is set.
r Push [CH Up] and [CH Down] several times to select the
desired frequency. The frequency changes according to
the wide/narrow setting.
t
Narrow channel spacing
(12.5 kHz steps)
Wide channel spacing
(25 kHz steps)
Push to select the desired digit to be altered.
☞ Continued on the next page.
To Next Page
