UNIT DESCRIPTION
2
Display ■
q
w r
o
i
uy
e
!0
!1 !4
!5 !6
!3
!2
t
q TRANSMIT INDICATOR
Appears when transmitting.
w BUSY INDICATOR
Appears while the channel is busy.
e SIGNAL STRENGTH INDICATOR
Indicates relative signal strength level. ➥
Blinks when ATS is in use. ➥
r TONE INDICATORS (p. 23)
“T” appears while the subaudible tone encoder is in use. ➥
“T SQL” appears while the tone squelch/DTCS squelch ➥
function is in use.
t BELL INDICATOR
Appears when the pocket beep function is in use. ➥
(p. 23)
Blinks when the specified selcall or smart ring call is ➥
received. (pp. 26, 28)
y QUIET INDICATOR
Appears when the quiet function is ON. (p. 27)
u PRIORITY CHANNEL INDICATOR
Appears when the priority channel is set. (p. 10)
i KEY LOCK INDICATOR
Appears when the keylock function is ON. (p. 8)
o BATTERY INDICATOR
Appears or blinks when the battery capacity decreases to
a specified level.
!0 ALPHANUMERIC DISPLAY
Displays the operating channel number, channel name,
set mode contents etc.
!1 FUNCTION INDICATOR
Appears when the function mode is ON. This allows sec-
ondary functions to be accessed.
