SPECIFICATIONS
D General
•Frequencycoverage
TX : 450–480 MHz
(includes all 80 CB channels)
RX : 450–520 MHz
•Mode :8K50F3E/16K0F3E
•Channelspacing
CB channel : 12.5 kHz
Private channel : 12.5/25 kHz
•Currentdrain(at7.2V) :TX(at5W) 1.9A
Max. audio 300 mA max.
•Powersupplyrequirement:7.2VDCnominal*
(negative ground)
*Specified Icom’s battery pack only
•Frequencystability :±2.5ppm(–30°Cto+60°C)
•Antennaimpedance :50Ω nominal
•Dimensions :53.0(W)× 120(H) × 37(D) mm
(Projections not included)
•Weight :
Approx. 310 g (including BP-232WP)
D Transmitter
•Outputpower :5W
•Modulationsystem :Variablereactancefrequency
modulation
•Max.frequencydeviation :±2.5kHz/±5.0kHz
•Spuriousemissions :70dB(min)
•Adjacentchannelpower :68dB/75dB(typical)
•Externalmic.connector :3-conductor2.5(d)mm/2.2kΩ
D Receiver
•Receivesystem :Doubleconversion
superheterodyne
•Sensitivity(12dBSINAD) :0.25µV(typical)
•Squelchsensitivity :0.25µV(typical;Threshold)
•Intermodulationrejectionratio :74dB(typical)
•Spuriousresponserejectionratio:70dB(min)
•Adjacentchannelselectivity :65dB/75dB(typical)
•Audiooutputpower :0.5W(typical)at5%distor-
tion with an 8 Ω load
•Externalspeakerconnector :2-conductor3.5(d)mm/8Ω
All stated specifications are subject to change without
notice or obligation.
