Table 2 continued. . .
Immunity
Test
IEC 60601 Test
Level
Compliance
Level
Electromagnetic Environment –
Guidance
Surge IEC
61000-4-5
±1 kV
differential
mode
±2 kV
common mode
±1 kV
differential
mode
±2 kV
common mode
Mains power quality should be
that of a typical commercial or
hospital environment.
Voltage
dips, short
interrup-
tions and
voltage
variations
on power
supply
input lines
IEC
61000-4-11
<5% U
T
(>95% dip in
U
T
) for 0.5
cycle.
40% U
T
(60%
dip in U
T
) for
5 cycles.
70% U
T
(30%
dip in U
T
) for
25 cycles.
<5% U
T
(>95% dip in
U
T
) for 5 sec.
<5% U
T
(>95% dip in
U
T
) for 0.5
cycle.
40% U
T
(60%
dip in U
T
) for
5 cycles.
70% U
T
(30%
dip in U
T
) for
25 cycles.
<5% U
T
(>95% dip in
U
T
) for 5 sec.
Mains power quality should be
that of a typical commercial or
hospital environment. If the user
of the iCR 3600 requires
continued operation during
power mains interruptions, it is
recommended that the iCR 3600
be powered from an
uninterruptible pwoer supply or a
battery.
Power
frequency
(50/60Hz)
magnetic
field IEC
61000-4-8
3A/m 3A/m Power frequency magnetic fields
should be at levels characteristic
of a typical location in a typical
commercial or hospital
environment.
NOTE: U
T
is the a.c. mains voltage prior to application of the test level.
