Ideal Heating EVOMAX 2 - Menu - Plant - Status - Real Time Values - Demand Inputs; Menu - Plant - Status - Real Time Values - Sensors; Menu - Plant - Status - Real Time Values - Outputs; Menu - Plant - Operating Mode

14
3.6.3 Menu – Plant – Status – Real time
values – Demand inputs
Onceinputsisselected,thenthefollowing
screen will display the current Real time
valuesfortheconguredInputs,onceagain
itemsthatarenotconguredwillbeshown
withnovaluebutwith2dashestoindicate
this, the list can be scrolled to show all
values:
Demand inputs
0-10V: - -
SL1: Off
OT1: - -
Demand inputs
0-10V: - -
SL1: Off
OT1: - -
Plant setp.: 0%
Demand inputs
SL1: Off
OT1: - -
Plant setp.: 0%
Plant setp.: 0.0ºC
Demand inputs
OT1: - -
Plant setp.: 0%
Plant setp.: 0.0ºC
Demand inputs
Plant setp.: 0%
Plant setp.: 0.0ºC
3.6.4 Menu – Plant – Status – Real time
values - Sensors
Oncesensorsisselected,thenthefollowing
screen will display the current Real time
values for the configured sensors, once
againitemsthatarenotconguredwillbe
shownwithnovalue but with 2 dashes to
indicatethis:
Sensors
Plant ow temp.: 37.5ºC
Outside temp.: - -
3.6.5 Menu – Plant – Status – Real time
values - Outputs
Onceoutputsisselected,thenthefollowing
screen will display the current Real time
values for the configured outputs, once
againitemsthatarenotconguredwillbe
shownwithnovalue but with 2 dashes to
indicatethis:
Outputs
Shared boiler pump: - -
System pump: - -
3.6.6 Menu – Plant – Operating mode
Theplantoperatingmodecanbeset.This
controls the operation of the complete
system, all boilers, all HCs and all DHW
circuits.Theoptionsare:
Operating mode
Off
Operating mode
Standby
Operating mode
Summer
Operating mode
Automatic
Off–Nooperation
Standby–Frostprotectiononly
Summer–NormaloperationbutnoHCs
Automatic–Fullautomaticoperation
3.6.7 Menu – Plant – Settings
The plant settings can be adjusted. The
options are:
Settings
Plant setp. SL1
OT temp. setpoint
Shared boiler pump
Settings
Plant setp. SL1
OT temp. setpoint
Shared boiler pump
Shunt Pump
Settings
OT temp. setpoint
Shared boiler pump
Shunt Pump
System pump
Settings
Shared boiler pump
Shunt Pump
System pump
PIDs
Settings
Shunt Pump
System pump
PIDs
Frost protection
Settings
System pump
PIDs
Frost protection
Boiler pump
Settings
PIDs
Frost protection
Boiler pump
Settings
Frost protection
Boiler pump
