3.7.6 Menu – Heating Circuits – Status
– Real time Values – Outputs
Once outputs is selected the screen will
showtheconguredlistofheatingcircuits:
Outputs
HC1 Boiler 1.1
HC2 Boiler 2.1
HC3 Boiler 2.2
Onceaheatingcircuitisselected,thenthe
following screen will display the current
Realtimevaluesfortheconguredoutputs,
onceagainitemsthatarenotconguredwill
beshownwithnovaluebutwith2dashes
to indicate this, the list can be scrolled if
requiredtoshowallvalues:
HC1 Boiler 1.1
Pump/valve: Off
3.7.7 Menu – Heating circuit –
Operating mode
Each heating circuit operating mode can
be set.This controls the operation of the
selectedHC.
Operating Mode
HC1 Boiler 1.1
HC2 Boiler 2.1
HC3 Boiler 2.2
Theoptionsare:
HC1 Boiler 1.1
Standby
HC1 Boiler 1.1
Time clock single day
HC1 Boiler 1.1
Time clock multiple days
HC1 Boiler 1.1
Day
HC1 Boiler 1.1
Night
Standby–Frostprotectiononly
Timeclocksingleday–Normaloperation,
timed
Timeclockmultipleday–Normaloperation,
timed
Day–Normaloperation,continuousdaymode
Night–Normaloperation,continuousnight
mode
3.7.8 Menu – Heating circuit – Room
temperature
Eachheatingcircuittargetroomtemperature
can be set for different operating modes for
theselectedHeatingcircuit.
Room temperature
HC1 Boiler 1.1
HC2 Boiler 2.1
HC3 Boiler 2.2
HC1 Boiler 1.1
Room temp day
Room temp night
Room temp holiday
HC1 Boiler 1.1
Room temp day
Room temp night
Room temp holiday
HC1 Boiler 1.1
Room temp night
Room temp holiday
Eachselected roomtemperaturesetpoint
canbeadjustedandthenset,theadjustment
screenisleftbypressingthebackbutton:
Room temp day
21ºC
3.7.9 Menu – Heating circuit – Flow
temperature
Each heating circuit ow temperature can
besetfordifferentoperatingmodesforthe
selectedHeatingcircuit.
Flow temperature
HC1 Boiler 1.1
HC2 Boiler 2.1
HC3 Boiler 2.2
HC1 Boiler 1.1
Flow temp day
Flow temp night
Flow temp holiday
HC1 Boiler 1.1
Flow temp day
Flow temp night
Flow temp holiday
HC1 Boiler 1.1
Flow temp night
Flow temp holiday
Eachselectedowtemperaturesetpointcan
be adjusted and then set, the adjustment
screenisleftbypressingthebackbutton:
Flow temp day
60ºC
ThislimitstheowtemperatureintoaHC.
3.7.10 Menu – Heating circuit – Settings
Eachheatingcircuithasanumberofsettings
thatcanbeadjustedfortheselectedHeating
circuit.
Settings
HC1 Boiler 1.1
HC2 Boiler 2.1
HC3 Boiler 2.2
HC1 Boiler 1.1
Preheat
Heating limit
Room temp. switch diff.
HC1 Boiler 1.1
Preheat
Heating limit
Room temp. switch diff.
Pump
HC1 Boiler 1.1
Heating limit
Room temp. switch diff.
Pump
Heating curve
HC1 Boiler 1.1
Room temp. switch diff.
Pump
Heating curve
Frost protection
HC1 Boiler 1.1
Pump
Heating curve
Frost protection
HC1 Boiler 1.1
Heating curve
Frost protection
