Ideal Heating EVOMAX 2 - Configuration; 5.1 System Manager Interface

25
Figure 4 SYSTeM MANAger iNTerFACe
5 CONFIGURATION
5.1 System Manager Interface
A. Rotary Knob
 • Enteramenu,ifinthenormaloperationscreen,andhighlighttherstmenuitem.
•
Scrollup(anti-clockwise)ordown(clockwise)inamenu
 • Changethevalueinparametersetting.
 • Ifanerrorisshowinginthetitlebar,scrolltotheassociatederrorscreen(s),andreturn.
B. LCD Display Screen
• Menu and status display.
C. Burner LED
 • Willbeoniftheburnerislit.
D. Select button
 • Enteramenu,ifinthenormaloperationscreen,andhighlighttherstmenuitem.
 • Enterthehighlightedmenu(submenuorparameter),ifinamenuorsubmenu.
 • Ifinaparametersetting,selectaparameterwhichwillthenashforadjustment,onceadjustedusingtherotaryknobpress
againtostoreandmoveon.
E. Back button
 • Inamenu,returntothepreviousmenulayer.
 • Inparametersetting,exittheparameterwithoutstoringthevalue.
 • Inaguidedassistant,gobacktothepreviousscreen.
F. Reset button
 • Resettheassociatedboilermoduleerror,ifaresettable(lockout)errorisactive.
 • Returntothenormaloperationscreen.
BACK
OK
A B C D E F
