1.12 prox.pad Specifications
Table 1: prox.pad Specifications
Electrical
Power Supply/Current Requirements 10-15 VDC, linear filtered and regulated power supply; 100mA
Wiring
Remote Antenna Cable (if installing in a
secured configuration)
[ALPHA 1294C (22AWG) 4-conductor, stranded and shielded]
Wiegand Interface Cable [ALPHA 1295C (22AWG) 5-conductor, stranded and shielded]
Secured Series Front End Cable [ALPHA 1295C (22AWG) 4-conductor, stranded and shielded]
Power Supply Cable 18AWG - 22AWG 2-wire stranded (depends upon distance)
Door Lock Cable 18AWG - 22AWG 2-wire stranded (depends upon distance)
Door Monitor Cable 18AWG - 22AWG 2-wire stranded (depends upon distance)
REX Cable
[ALPHA 2421C 18 AWG or ALPHA 1292C 22 AWG, 2-conductor,
stranded and shielded] (if using remote switch)
Mechanical
Height 5.25 in (13.3 cm)
Width 2.75 in (7 cm)
Depth 1.625 in (4.13 cm)
Relay Outputs
Main Relay Form C (switches up to 2A)
Program for either timed (1-99 sec) or toggle
Aux Relay Form C (switches up to 1A)
One of three functions can be programmed: Alarm Shunt Relay,
Forced Door Relay, or Propped Door Relay
Monitor Inputs
Door Position Switch Normally Closed, Dry Contact
Other Outputs
Infrared LED Output Output to optional Data Collection Device PDA Software
Sounder 4000 Hz, defeatable
Bi-Color LED Red/Green
Yellow LED
Compatible Proximity Cards (All HID cards up to 40 bits, including the following)
Prox Card II, IsoProx II, DuoProx II, ProxKey FOB
Specifications continued on next page.
Page 12 of 86 Document # 6055676, Rev 2.2, D4b

IEI Technology prox.pad Specifications

General

Brand	IEI Technology
Model	prox.pad
Category	Keypad
Language	English
