prox.pad Installation/Programming Manual
3.4 Wiegand Programming Commands
If you need to change any of the program default values or wish to add functions, first enter program mode and then enter the desired
program command. Defaults are in bold.
Note: The master code must be changed prior to performing any programming on the prox.pad unit.
Table 10: Wiegand Programming Commands
Action Desired Press Details
Enter Program Mode 99 # (Master Code)* Yellow LED blinks slowly
Change master code 1 # (new code) * (repeat code) *
Ex: 1 # 4321 * 4321 *
Code-only operation
Set/clear standard option 30 # option # s/c # ** See Chart below
Option Set Clear
0 – Audio Keypress Feedback 1 = Enabled 0 = Disabled
1 – Visual Keypress Feedback 1 = Enabled 0 = Disabled
2 – Auto Entry 0 = Disabled 1 = Enabled
3 – Operating Mode 0 = Standalone 1 = Front End
9 – Wiegand Red LED Enable 0 = Disabled 1 = Enabled
10 – Wiegand Red LED Active State 0 = Low 1 = High
11 – Wiegand Geen LED Enable 0 = Disabled 1 = Enabled
12 – Wiegand Green LED Active State 0 = Low 1 = High
15 – Front End Mode Select 0 = Wiegand Front End 1 = Secured Series Front
End
Change Platform Parameters 32 # parameter # value # ** See Chart Below
Parameter Value
0 – Wiegand Pulse Width 1 – 255; 20μS increments;
(Defaults to 8 = 160μS)
1 = Wiegand Interpulse Spacing 1 – 255; 20μS increments;
(Defaults to 32 = 640μS)
2 – 26-Bit Facility Code (for keypad output) 0 – 255 (Default = 1)
Delete Entire Memory and Reset
System Defaults
46 # 00000 # 00000 # **
To exit Program mode Press * Yellow stops flashing
Document # 6055676, Rev 2.2, D4b Page 69 of 86
