prox.pad Installation/Programming Manual
2.7.1.c prox.pad LED Indicators/Sounder Operations – Standalone Mode
The table below describes the various LED and Sounder indications used in the prox.pad while operating in standalone mode.
Table 5: prox.pad LED Indicators/Sounder Operations – Standalone Mode
LED/Sounder Visual/Audible Condition Description
Yellow LED
Slow blink Unit is in Program mode
Rapid blink
Verify mode is active (checking that the last two values in
sequence match)
Steady Program error; entry error lockout (no keypress feedback)
Very rapid blink Memory (eeprom) erase is in progress (command 46)
“Pulsing” rapid blink
Batch program of cards in progress (command 56); block
delete of users (command 58)
Bi-color LED
Steady red Lock is locked
Steady green Lock is energized (timed or latched)
Red drop out
Lock locked, user lockout is active; red LED drops out for
100 ms every second; a latched lock will override lockout
indicator
Green with red blink Lock latched and user lockout is active
Fast green flash IR dump in progress (user/log)
Quick double red/green flash Prox card read correctly
Alternating red/green Waiting for second PIN or “card and code” user
Solid green with red flicker Lock toggle is unlocked and user lockout active
Red blink
User lockout is active and lock locked; red LED drops out
for 100 ms every second; normal users cannot change
the state of the relay
All LED's
Rapid red, yellow, green
sequencing
Power on/reset
Sounder
(system)
Very quick beep (10 ms) with
yellow LED blink every second
EEPROM read error during get system parameters; can
be turned off by running self-test
Short beep (100 ms) every 2
seconds
Propped door is active
Sounder 1/2 sec on, 1/2 sec off Forced door is active
Sounder (after
PIN)
3 rapid beeps after PIN not found
Sounder (after
card)
3 very rapid beeps
PIN not found, facility code/company ID mismatch and
access by facility mode enabled; incorrect card type
(option #20)
1 short beep Valid card access
Document # 6055676, Rev 2.2, D4b Page 37 of 86
