prox.pad Installation/Programming Manual
3.3.17 Wiegand Mode LED Indicators/Sounder Operations
The table below describes the various LED and sounder indications used in the prox.pad while in Wiegand Front End Mode.
Table 9: prox.pad LED Indicators/Sounder – Wiegand Mode
LED/Sounder Visual/Audible Condition Description
Yellow LED
Slow blink Unit is in Program mode
Rapid blink
Verify mode is active (checking that the last two values in
sequence match)
Steady Program error; entry error lockout (no keypress feedback)
Very rapid blink Memory (eeprom) erase is in progress (command 46)
Bi-color LED
Steady red Lock is locked
Steady green Lock is energized (timed or latched)
Quick double red/green flash Prox card read correctly
All LED's
Rapid red, yellow, green
sequencing
Power on/reset
Sounder
(system)
Very quick beep (10 ms) with
yellow LED blink every second
EEPROM read error during get system parameters; can
be turned off by running self-test
Sounder (after
PIN)
Single long beep
Value entered too big, cannot be represented in 16 bits
(Wiegand mode)
Sounder (after
card)
1 short beep Valid card access
3.3.18 Wiegand Front End Mode Default Settings
Option Default Setting Option Default Setting
Master Code 1234 Audio Keypress Feedback Enabled
Visual Keypress Feedback Enabled Auto-Entry Disabled
Wiegand RED LED Enabled Red LED Active State Low
Wiegand Green LED Enabled Green LED Active State High
Pulse Width 8 = 160μS Inter-pulse Spacing 32 = 640μS
Page 68 of 86 Document # 6055676, Rev 2.2, D4b
